Removable Insulation Sleeve Hook Head Stainless Steel Insulation Lacing Anchor

Ask Lasest Price
Brand Name :	HUIHAOCUSTOM
Model Number :	SS-22
Certification :	ISO9001-2015
Payment Terms :	L/C, D/A, D/P, T/T
Supply Ability :	500000 pcs per 30 days
Delivery Time :	7 work days

Add to Cart

Product Details
Company Profile

Removable Insulation Sleeve Hook Head Stainless Steel Insulation Lacing Anchor

General description of insulation lacing anchor

The Lacing Anchor is a fabricated metal anchor consisting of a pin and tabbed ,or hooked washer . Stainless steel is a popular material while some Lacing Anchors are made in Mild steel .

Technical Specification of insulation lacing anchor

Pin Material	Anneaded stainless steel wire, anneaded mild steel wire , copper wire is for special orders
Hook Material	1MM thickness Stainless steel ,galvanized steel
Length(L)	2-1/2” ( 63 mm )& 4-1/2” ( 114 mm ) are standard , other lengths available by special order
Pin diameter	12ga & 14ga are standard . Other sizes are available by special order .

images details of insulation lacing anchor

Removable Insulation Sleeve Hook Head Stainless Steel Insulation Lacing Anchor

Applications of insulation lacing anchor

Lacing Anchors are used in the fabrication of insulation blankets or removable covers/pads. The nail is pressed through the insulation material, so the hook portion sits on the top edge and the nail is secured on the opposite side of the insulation with a washer. The two sides of the blanket can then be "laced" together by the hooks with tie wire

Removable Insulation Sleeve Hook Head Stainless Steel Insulation Lacing Anchor

XIANGYI METAL

Removable Insulation Sleeve Hook Head Stainless Steel Insulation Lacing Anchor
