Decorative Drapery Fabric Metal Mesh Curtain For Interior Wall
Design
Quick details of metal curtain mesh
- Material: stainless steel ,aluminum alloy
- Aperture diameter: 5–9mm.
- Diamond height: 5–9 mm.
- Wire diameter: 1mm– 1.2 mm.
- Diamond width: 6–16mm.
- Open area: 40% – 85%.
- Weight: 4.2–6 kg/m2. (depending on material and size chosen)
- Coil length & mesh panel width: customized.
- Surface treatment: pickling, anodic oxidation and baking varnish
Specification details of metal curtain mesh
Material | Wire diameter (mm) | Aperture(mm) | Theoretical Weight (kg/m2) | Surface Treatment |
AISI 304/316 | 1 | 5 | 3.3 | Natural polished |
1 | 8.4 | 3.5 |
1.2 | 6.8 | 5.8 |
Al-Mg Alloy | 1.2 | 4 | 1.9 | Paint-spray Anodizing |
1.2 | 5 | 1.5 |
1.2 | 6 | 1.25 |
1.2 | 7 | 1.13 |
1.2 | 8 | 1.2 |
1.2 | 9 | 0.85 |
Aluminum | 1 | 5.5 | 1.5 |
1.2 | 6.8 | 2.5 |
1.2 | 8.5 | 2 |
Carbon Steel | 0.9 | 6.3 | 4 |
1 | 6.8 | 5.5 |
1.2 | 8.5 | 6 |
Details of the coil weave mesh
Description of metal curtain mesh
- Light diffusion and good ventilation
- UV resistant and flame resistance
- Beautiful appearance and various color option
- Excellent Aesthetic appeal and functionality
- Color never fading and paint never dropping
- Gorgeous and chic elegant appearance
- Good durability and flexibility
- Unlimited creativity and artistic aesthetic
Images of metal curtain mesh
Installation frame dersign for metal curtain mesh
How to Measure:
Including all replacement screen sets. Screen height does not include the height of the hanging rings. The
included hanging rings add 1/2" to the height of the screen. Replacing an existing screen: Measure the height and width of the
existing screen (not including the hanger rings) and order the same
height screen. Adding a screen to an existing rod: Measure the height of your
fireplace opening and subtract 1-inch.
Purchasing screen with an adjustable rod & valance kit: Measure the
height of your fireplace opening and subtract 2-inches.
Applications of the metal curtain mesh
Metal metal mesh Drapery with versatility, variety of color,
durability and flexibility, metal coil drapery provides a new decoration style for various
functions and practical areas.Such as:
1)Curtain: shower curtain, window curtain, door curtain, fireplace
mesh curtain,etc.
2)Space divider: for home, office, restaurant, hotel, supermarket,
etc.
3)For decoration: light partitioning, exhibition hallsceilings,
wall covering, display, etc.
4)For protection: cladding, facade, enclosures, shades, etc.
