Aluminum Alloy Stainless Steel Bimetallic CD Weld Pins

Ask Lasest Price
Brand Name :	HUIHAOCUSTOM
Model Number :	CDM3
Certification :	ISO9001-2015
Payment Terms :	L/C, D/A, D/P, T/T
Supply Ability :	7000000 SETS PER MONTH
Delivery Time :	10 WORK DAYS

Add to Cart

Product Details
Company Profile

Aluminum Alloy Stainless Steel Bimetallic CD Weld Pins

Deck Board M3 Aluminum Alloy Stainless Steel Bi-Metallic CD Weld Pins

Quick details of the Deck Board M3 Aluminum Alloy Stainless Steel Bi-Metallic CD Weld Pins

CD Weld pinsTypes : bi-metallic pins
Material: stainless steel pins, aluminum alloy base
Surface treratment: polished for stainless steel and aluminum pins.
Pin diameter: 2.7mm and 3mm
Length: 15mm-300mm


Simple construction	high fficiency	saving labors	Eeasy weld to fasten the insulation	Pins sharp for easy go through any insulation

Specification of Deck Board M3 Aluminum Alloy Stainless Steel Bi-Metallic CD Weld Pins

photo	name	Specifications of the Bimetallic Insulation Pins
	Material	Aluminum base material +Stainless steel /Copper/Zinged steel
	Base size	6*13mm in common
	Pin diameter	3.0mm in common , Customized diameter is also available
	Pin types	sharp point and flat head
	Length	15-150mm, length could be customized .

Images of the Deck Board M3 Aluminum Alloy Stainless Steel Bi-Metallic CD Weld Pins

Installation parts-self locking washer / dome cap washers

Aluminum Alloy Stainless Steel Bimetallic CD Weld Pins

application equipments of Deck Board M3 Aluminum Alloy Stainless Steel Bi-Metallic CD Weld Pins

PowerPinner 7100 Light Duty, Hand Welder
PowerPinner 7200 Heavy Duty, Portable Hand Welder
PowerPinner 7005 Rapid Fire Fixed Head Welder
PowerPinner 7105 Rapid Fire Moving Head Welder
PowerPinner 50 Multi-head Welder
SAM Replacement Controller for Coil Line Pinners

recommended for	pin length before welding
1/2" insulation(all densities)	12.67mm
1" insulation(1-1/2"ib density)	17.63mm
1" foam	25.55mm
1"insulation(3ib densities)	23.72mm
1-1/2" insulation(all densities)	28.42mm
2"insulation(1-1/2"-2" ib density)	37.95mm
2"insulation(3ib densities)	48.77mm
3"insulation(all densities)	69.85mm
4" insulation(all densities)	95.00mm

Package details of cd weld bi-metallic pins

pin length	qty/bag	carton size	bags/carton
15mm-38mm	500pcs	41cmx28cmx18cm	10 bags
40mm-65mm	500pcs	41cmx28cmx18cm	8 bags
70mm-90mm	400bags	41cmx28cmx18cm	7 bags
other size	custom	custom

FAQ

1-What is your min quantity?

-Min order value is not less USD500.

2-What is the normal delivery date?

-20-25 days against the deposit received.

3-What products is your self-produced?

-All stamping and all plastic parts.

4-Where is your main market?

-USA, Gulf Countries and East Europe.
