280mm Stamped Hole Base Insulation Bonding Fastener Hanger Pins

Ask Lasest Price
Brand Name :	HUIHAOCUSTOM
Model Number :	PER-50-s
Certification :	ISO9001-2015
Payment Terms :	L/C, D/A, D/P, T/T, Western Union
Supply Ability :	10000 pcs oer hour
Delivery Time :	10 work days

Add to Cart

Product Details
Company Profile

280mm Stamped Hole Base Insulation Bonding Fastener Hanger Pins

Specification details of the insulation hanger pins

part No.	base type	pin diameter in standard	pin length in standard
per-s-25	25mmx25mm square	1.8mm	25mm-62mm
per-s-40	40mmx40mm square	2.5mm	15mm-110mm
per-s-50	50mmx50mm square	2.7mm or 3mm	38mm-203mm

other size can be customized, stainless steel material is for special orders.

Key questions of insulation hanger pins

1. Why choose aluminum material wire and spft steel wire to make the pins?

aluminum wire is soft, easily for bending. 2.7mm or 3mm pin diameter have enough strength to support the insulation material

2. why choose the galvanized steel plate or stainless steel plate for making the base?

0.4mm thickness steel or stainless steel plate is enough hardness to avoid deformed. Riveting firmly, nails will not fall off.

3. how to rustproof?

zinc coated or copper plating is rustproof treatment. the best material is stainless steel, but the cost is high.

image details of the insulation hanger pins

280mm Stamped Hole Base Insulation Bonding Fastener Hanger Pins

Application of the insulation hanger pins

HVAC ducting
Noise insulation attachment in marine engine rooms, bus and truck engine bays, compressor enclosures etc

HEBEI XIANGYI METAL PRODUCT CO.,LTD

280mm Stamped Hole Base Insulation Bonding Fastener Hanger Pins

Insulation pins and self locking speed clip is most popular in international market. We have owned a lot of customers from Europe, Australia, Middle East, Southeast Asia and North America.

One-to-one order service
Door to door logistics service
Cartographic confirmation service
Processing customization service
Packaging design service
Document making service
Inspection and inspection service
