Galvanized Steel M8 Insulation Fixing Pins For Fixing Building Board Wall

Ask Lasest Price
Brand Name :	HUIHAOCUSTOM
Model Number :	XY-GS-M8
Certification :	ISO9001-2015
Payment Terms :	L/C, D/A, D/P, T/T
Supply Ability :	400000SETS PER 28 DAYS
Delivery Time :	7 WORK DAYS

Add to Cart

Product Details
Company Profile

Galvanized Steel M8 Insulation Fixing Pins For Fixing Building Board Wall

Galvanized steel M8 insulation fixing pins for fixing building board wall

Introductions of the M8 insulation fixing pins

Galvanized steel M8 insulation fixing pins is suit for the soft and pressure-resistant insulating materials, such as glass wool, rock wool, polystyrene, PU panels, foam glass, lighting building boards made of wood wool, coir matting, cork boards etc.

Material :galvanized steel or stainless steel
Material thickness: 0.7mm
Base:35mm diameter washer with round holes.
Pin diameter:8.0mm
Pin/plug length:50mm/60mm/90mm/110mm/140mm/170mm/200mm/230mm , etc
Packing:250pcs/box, then put on pallet, also could be packed as request.


Size	Pin length (L)	Pin dia(D)	Base size (A)	Material thickness(T)	Packing
M8*50mm	50mm	8mm	35mm	0.7mm	250pcs per carton, also could be packed according to the customized requirements.
M8*60mm	60mm
M8*90mm	90mm
M8*110mm	110mm
M8*140mm	140mm
M8*170mm	170mm
M8*200mm	200mm
M8*230mm	230mm
Customized length and base size is available for larege order .

Detail photos of the M8 insulation fixing pins

Galvanized Steel M8 Insulation Fixing Pins For Fixing Building Board Wall

Application of the M8 insulation fixing pins:

Suitable for: Concrete,Natural stone with dense structure,Solid brick,Solid sand-lime brick ,Solid block made from lightweight concrete,Aerated concrete,Vertically perforated brick,Perforated sand-lime brick For fixing for: Soft and pressure-resistant insulating material, e.g.,Glass wool,Rock wool,Polystyrene, Pu panels, Foam glass, Lighting building boards made of wood wool, etc

Note the installation of the M8 insulation fixing pins:

70mm insulation fasteners for 20-40mm insulation panels
90mm insulation fasteners for 40-60mm insulation boards
110mm insulation anchors for 60-80mm insulation slabs
130mm insulation anchors for 80-100mm insulation slabs
150mm insulation fixings for 100-120mm insulation slabs
180mm insulation fixings for 120-150mm insulation boards

Highly versatile in a wide range of construction materials
Fix with hammer or SDS drill adapter
Fixes into concrete and masonry with tiny pilot hole
Fixes directly into lightweight block without pre-drilling

Galvanized Steel M8 Insulation Fixing Pins For Fixing Building Board Wall

XIANGYI METAL INTRODUCTION

FAQ

Q1. How about the Delivery time?
A. About 20-35 days.
Q2. What kind of payments does jenor support?
A. T/T,L/C ,D/Pare accepted or other methods negotiable.
Q3. Can you produce according to customers' design?
A. Sure, we are professional manufacturer, OEM and ODM are both welcome.
We'll offer you the quotation as soon as possible once receive your inquiry,so don't hesitate to contact us. We can produce the product under your brand name, also the size can be changed as your requirement.
